Emergency Power Transfer Dual Power Switch YRQ2PC-125A
Emergency Power Transfer Dual Power Switch YRQ2PC-125A
The YRO 2P 125A dual power automatic transfer switch, is a product specially designed for switching between the generator and the mains power. When the mains power suddenly goes out, it can help you switch to generator power supply within 0.03 seconds, and neither the refrigerator nor the air conditioner will shut down. It has passed the EU CE safety certification, making it more reassuring to use.
GET A QUOTE
This content will appear inside a popup…
Product Introduction
The automatic power switching system is primarily connected to the public power grid for power supply during daily operation. Its core processor can monitor abnormal changes in input voltage in real time. When the power quality is detected to be substandard, the system can activate the standby generator set within 0.03 seconds. After the mains power parameters return to normal and pass the stability verification, the equipment will automatically switch back to the main power supply line. This operation mechanism has fully realized the intelligent management of unattended operation.
The design has particularly taken into account the installation needs of ordinary users. The 2P (two wire) design corresponds to 110V and 220V voltages, and can be used in various living scenarios such as homes and small stores. The indicator lights are very intuitive. The main power supply and the backup power supply are respectively equipped with red indicator lights. When the main power supply is not powered on, the corresponding indicator light is off. Once powered on, the indicator light lights up immediately. The indicator light of the backup power supply is the same.
The shell is made of flame retardant engineering plastic, and can withstand the high temperature environment commonly found in computer rooms.
Product Description
- Fast switching: When the main power supply fails, it only takes 30ms to automatically switch to the backup generator power supply, ensuring continuous power supply to the equipment.
- Safety Certification: The product has passed the CE certification and complies with international safety standards.
- Wide application: It is suitable for households, small commercial places and small factories and other occasions that require generator backup power.
Product Feature
- An internal disconnector is installed, providing an additional layer of protection for electricians.
- A standard 35mm guide rail installation position is reserved at the bottom, and the installation can be completed with an electrician’s screwdriver.
Product Parameters
| Product Series | YRQ2PC-125 |
| Pole | 2P |
| Rated Current | 125A |
| Rated Voltage | 220V |
| Changeover Time | <30ms |
| Operation Voltage | 180~270V |
| Ambient Temperature | -20 ~ +70℃ |
